Graco LTX219 - RAC X LTX SwitchTip (219)
Graco LTX219 - RAC X LTX SwitchTip (219)
Low stock: 1 left
Couldn't load pickup availability
Graco LTX219 - RAC X LTX SwitchTip (219)
Precision narrow-surface finishing - Model LTX219. The Graco LTX219 RAC X LTX SwitchTip is made for narrow surfaces and thicker materials. It delivers a consistent 4 to 6 inch fan with a 0.019 inch orifice and features quick reverse action to clear clogs and keep jobs moving.
What’s Included
- (1) RAC X LTX SwitchTip - LTX219
Key Features
- 0.019 inch orifice for fine atomization on narrow surfaces
- Produces a 4 to 6 inch fan ideal for trim, cabinets, and tight areas
- Reverse-A-Clean action reverses the tip to eject clogs without tools
- OneSeal tip gasket installs by hand; solvent seal available for hot solvents
- Locking tab secures the tip in the guard and snaps between spray and reverse positions
- Large raised tip size numbers remain legible even when covered with material
Specifications
- Part / Model: LTX219
- Series: LTX SwitchTip - RAC X family
- Orifice diameter: 0.019 in
- Pattern size: 4 to 6 in
- Maximum flow rate: 0.38 GPM (1.44 L/min)
- Maximum working pressure: 4050 psi
- Compatible materials: lacquer to mastic, latex paint
- For use with RAC X HandTite tip guard
- Tip type: airless switch tip
Care & Use
- Hand-tighten the OneSeal tip gasket and verify seating before spraying
- Use reverse action to clear clogs rather than forcing tips with tools
- Flush tip thoroughly after each use to prevent material build-up and preserve fan quality
- Replace tip when the fan pattern becomes uneven or worn
- Store tips in a clean, dry place to protect the precision orifice
Graco LTX219 - a narrow-surface RAC X tip built for precise, low-overspray finishing and fast maintenance on professional jobsites.
